Grounding is the approved and best way to drain off static charges. You can eliminate static accumulation with the use of static grounding clamps. Static Grounding Clamps connection shall be made fast to the tank or vehicle before dome covers are raised and shall remain in place till the time loading or unloading is completed. As an when combustible or flammable liquids are transferred in one container from another container both containers shall be effectively bonded and grounded to prevent discharge sparks of static electricity.
Earthwell Industries manufactures Static Grounding Clamps used to ground Tanks, Drums, Containers, Equipment etc. These static grounding clamps are widely used to load or unload hazardous materials from Tanks, Drums, Containers Etc. Static Grounding Clamps are best solution to discharge static charge generated while loading or unloading of hazardous materials.
Earthwell Industries manufactures two types of static grounding clamps. Regular Static Grounding Clamps and Spiral Grounding Clamps.
Static Grounding Clamps
Static Grounding Clamps manufactured by Earthwell Industries are 100% customizable. You can select type of braid, area of braid, type of clamp & length of wire. These clamps are useful for temporary grounding applications to discharge static electricity and need to wind or unwind manually.
Our Standard Manufacturing Range is,
Types
Lengths
Braid Area
Material Options
Clamp Options
Flat Copper Braid or Round Copper Braid.
500 mm to 15 meters.
2.5 sq. mm to 50 sq. mm.
Bare Copper, Tin Plated Copper or Insulated Copper.
MS with zinc plating or SS 304 on both side or one side.
Spiral Grounding Clamps
Spiral Grounding Clamps manufactured by Earthwell Industries are best option for temporary grounding applications to discharge static electricity. The main advantage of Spiral Grounding Clamps is unlike regular static grounding clamp it need not wind after use. Due to its spiral design it automatically comes to its actual spiral shape and its best solution for tangled wires of long length.
Our Standard Manufacturing Range is,
Standard Types
Standard Lengths
Cable Sizes
Material Options
Clamp Options
Uninsulated Braid or Insulated Cable.
3 meters, 5 Meters, 10 Meters.
2.5 sq. mm to 10 sq. mm.
Bare Copper, Tin Plated Copper or PVC Cable.
MS with zinc plating or SS 304 on both side or one side.
Earthwell Industries Manufactures Following Items,
Copper Wire Braided Strips, Copper Wire Braided Ropes, Copper Wire Stranded Ropes, Copper Braids, Copper Earthing Jumpers, Braided Earthing Jumpers, Copper Jumpers, Earth Braids, Flange Earthing Jumpers, Copper Jumpers, Strip Type Copper Jumpers, Earth Continuity Strap, Static Earthing Jumper, Static Grounding Clamps, Spiral Grounding Clamps, Bonding Jumpers, Copper Flexible Braids, Copper Braid Bonds etc.
